Overview:
The Veneer Peeling Machine is a piece of equipment used in the woodworking industry to peel veneers from logs of wood. It uses a rotating blade to slice the wood into thin, uniform sheets that can be used for various purposes, such as furniture, flooring, and decorative paneling. This machine is designed for efficiency, speed, and accuracy, allowing woodworkers to produce high-quality veneers with ease.
Features:
• High-speed peeling: The machine can peel veneers at a high speed, ranging from 30 to 60 meters per minute, depending on the model.
• Precision cutting: The machine uses a precision blade that ensures uniform thickness and smoothness of the veneers, resulting in high-quality end products.
• Automatic log centering: The machine automatically centers the logs, ensuring that the veneers are sliced evenly and without any waste.
• Easy operation: The machine is easy to operate and requires minimal training, making it suitable for both large-scale and small-scale operations.
• Safety features: The machine is equipped with safety features, such as emergency stop buttons, safety guards, and sensors that prevent the machine from operating if any safety issues are detected.
Parameter |
Model | GTPM150mm | GTPM270 | GTPM360 |
Roller Length | 1300mm | 2600mm | 3300mm |
Max Processing Log Diameter | Φ550mm | Φ600 | Φ700 |
Min Residual wood Diameter | Φ32mm | Φ32mm | Φ30mm |
Single Roller Diameter | Φ100 | Φ125 | Φ125 |
Double Roller Diameter | Φ125 | Φ125 | Φ125 |
Working thickness Range | 1.0mm to 4.0mm | 1.0 to 4.0mm | 1.0 to 4.0mm |
Peeler Blade size | 150*160*13mm | 2700*180*16mm | 3600*180*16mm |
Main Line Speed | 0-80m/min ,adjustable | 0-80m/min ,adjustable | 0-80m/min ,adjustable |
Total Power | 45.4KW | 60KW | 86.5KW |
Overall Size(L*W*H) | 4500* 2250*1450mm | 5800* 2250*1650mm | 6500*2250*1850mm |
Weight (KGS) | About 6800KG | About 9000KGS | About 13000KGS |
